Pure Energy Solutions for Sub-Saharan Africa



Generators

Lean Green Power Machines

Energie range of power products are designed and developed with the future in mind. Offering the maximum permissible power output in both diesel and petrol options, Energie Power delivers fuel efficiency across all ranges in the most demanding applications and environments.

​RETURN TO PORTABLE GENERATOR MAIN PAGE

​RETURN T​​O VERT ENERGY HOME PAGE

​RETURN TO SPARE PARTS HOME PAGE

Product Range Overview

Refer to the table below

Characteristics

  • Engine Type Vertical Cylinder, 4-Stroke
  • Power 4.2kW - 15.0kW
  • Cylinder Single & V-Twin
  • Speed 3000 & 3600rpm
  • Cooling Forced Air-Cooling by Flywheel Fan
  • Starting System Recoil or Electric
  • Frequency Option 50Hz & 60Hz
  • Fuel Diesel or Petrol
  • Emissions Regulations Non-Regulated Territories

Diesel Generator Range

Overview

Single Phase Generator Model

  • Alternator Model Engine Model (Single Cylinder)
  • K100E VPHLD420-M
  • K100E VPHLD420-E
  • K100G VPHLD475-M
  • KR100G VPHLD475-E

  • Alternator Model Engine Model (V-Twin Cylinder)
  • CR112SB VPHLD1000-M

Output Rated

  • Single Phase Model (Single Cylinder) kVA.....Regulation........V
  • VPPVG_D_4500M 4.2.....Capacitor.....220v
  • VPPVG_D_4500E 4.2.....Capacitor.....220v
  • VPPVG_D_6000M 6.0.....Capacitor.....220v
  • VPPVG_D_6000E 6.0.........AVR.........220v

  • Single Phase Model (V-Twin Cylinder) kVA.....Regulation........V
  • VPPVG_D_10000M 10.0.........AVR.........220v
  • Values are at Rated Continuous Power 3000rpm 50hz, 1000masl 1.0pF 27 Deg C

Three Phase Generator Model

  • Alternator Model Engine Model (Single Cylinder)
  • ZR100SC VPHLD475-E

  • Alternator Model Engine Model (V-Twin Cylinder)
  • ZR100LB VPHLD1000-M

Output Rated

  • Single Phase Model (Single Cylinder) kVA.....Regulation........V
  • VPPVG_D_6000M 6.0.........AVR.........400v

  • Single Phase Model (V-Twin Cylinder) kVA.....Regulation........V
  • VPPVG_D_10000M 10.0.........AVR.........400v
  • Values are at Rated Continuous Power 3000rpm 50hz, 1000masl 1.0pF 27 Deg C

Welder Model

  • Alternator Model Engine Model (Single Cylinder)
  • WS200AC VPHL460-M

Output Rated

  • Welder Model
         kVA.....Regulation........V
  • VPPVGW_D_6000M 6.0.....Capacitor.....220v
  • Values are at Rated Continuous Power 3000rpm 50hz, 1000masl 1.0pF 27 Deg C

Petrol Generator Range

Overview

Single Phase Generator Model

  • Alternator Model Engine Model (Single Cylinder)
  • K100G VPHL460-M
  • KR100G VPHL460-M
  • C100LH VPHL460-M

  • Alternator Model Engine Model (V-Twin Cylinder)
  • CR112SB VPHL690-E
  • CR112SC VPHL750-E
  • CR112MA VPHL1000-E

Output Rated

  • Single Phase Model (Single Cylinder) kVA.....Regulation........V
  • VPPVG_P_6000M 6.0.....Capacitor.....220v
  • VPPVG_P_6000M 6.0.........AVR.........220v
  • VPPVG_P_7000M 7.0.....Capacitor.....220v

  • Single Phase Model (V-Twin Cylinder) kVA.....Regulation........V
  • VPPVG_P_10000E 10.0.........AVR.........220v
  • VPPVG_P_12000E 12.0.........AVR.........220v
  • VPPVG_P_15000E 15.0.........AVR.........220v
  • Values are at Rated Continuous Power 3000rpm 50hz, 1000masl 1.0pF 27 Deg C

Three Phase Generator Model

  • Alternator Model Engine Model (Single Cylinder)
  • ZR100SC VPHL460-M

  • Alternator Model Engine Model (V-Twin Cylinder)
  • ZR100LB VPHL460-E
  • ZR112SC VPHL750-E
  • ZR112SC VPHL1000-E

Output Rated

  • Single Phase Model (Single Cylinder) kVA.....Regulation........V
  • VPPVG_P_7000M 7.0.........AVR.........400v

  • Single Phase Model (V-Twin Cylinder) kVA.....Regulation........V
  • VPPVG_P_10000E 10.0.........AVR.........400v
  • VPPVG_P_12000E 12.0.........AVR.........400v
  • VPPVG_P_15000E 15.0.........AVR.........400v
  • Values are at Rated Continuous Power 3000rpm 50hz, 1000masl 1.0pF 27 Deg C

Welder Model

  • Alternator Model Engine Model (Single Cylinder)
  • WS200AC VPHL460-M

Output Rated

  • Welder Model
         kVA.....Regulation........V
  • VPPVGW_P_7000M 7.0.....Capacitor.....220v
  • Values are at Rated Continuous Power 3000rpm 50hz, 1000masl 1.0pF 27 Deg C

Residential Generator Range

Overview

Single Phase Generator Model

  • Alternator Model Engine Model
  • VP6000 VPHL460-M
  • VP8000 VPHL460-M

Output Rated

  • Single Phase Model kVA.....Regulation........V
  • VPP_HLG6000E 6.0.........AVR.........220v
  • VPP_HLG8000E 7.0.........AVR.........220v
  • Values are at Rated Continuous Power 3000rpm 50hz, 1000masl 1.0pF 27 Deg C

Three Phase Generator Model

  • Alternator Model Engine Model
  • VP8000 VPHL460-M

Output Rated

  • Three Phase Model kVA.....Regulation........V
  • VPP_HLG8000E 7.0.........AVR.........400v
  • Values are at Rated Continuous Power 3000rpm 50hz, 1000masl 1.0pF 27 Deg C

Spare Parts & Technical Support

Please click on the link below for spare parts service and maintenance

​  Purchase Parts Online

DOWNLOAD:

Brochures

Technical Data Sheet

Options

Drawings

Maintenance and Parts Manual
