Pure Energy Solutions for Sub-Saharan Africa



Hybrid Series

GOING ONCE. GOING TWICE. GOING GREEN BEFORE ITS GONE

The Hybrid Range by Halo offers customers in sunny areas the perfect solution by day to ensure that their operations continue seamlessly at night.


Three monocrystalline panels with MPPT charging ensure that your batteries are optimised for a full 15 hour operating cycle at full load. As a backup to the system an optional standby generator is available. The unit is powered by an air-cooled Yanmar Diesel Engine as a redundancy option at night or when cloud cover has disrupted the required charge cycle.


The Hybrid range is the greener alternative within our standard range of products.


Model: HHLT1600-220-S-4x350PV

             HHLT4200-220-S-4x350GEN

​RETURN TO LIGHTING TOWER MAIN PAGE

​RETURN TO HALO HOME PAGE

​RETURN T​​O VERT ENERGY HOME PAGE

​RETURN TO HALO SPARE PARTS PAGE

Product Overview

Refer to the table below

Engine Characteristics (Optional)

  • Engine Single Cylinder Air Cooled Four Stroke
  • Make/Model Yanmar L70-DEGLT
  • Fuel Consumption 1.176 l/ph At Full Load
  • Cooling Air Cooled Naturally Aspirated
  • Output 4kW Continuous
  • Revolution (RPM) 3000 rpm
  • Electric System 12V
  • Starting Method Electric
  • Number of Cylinders 1
  • Displacement L(cu, in) 0.320L
  • Engine Shutdown Protection Low Oil Pressure

  •      High Water Temperature

  •      Low Fuel

Alternator Characteristics (Optional)

  • Make/Model NSM K100E
  • Output 4.2kVA
  • Frequency 50Hz 3000rpm
  • Voltage Output 220V AC
  • Coupling J609B
  • Regulation Capacitor
  • Insulation H

  • Controller Characteristics

  • Controller Smartgen ALC404
  • Breaker Make and Size ABB or Equivalent 16A
  • IP Protection IP55
  • Battery Charger Smartgen
  • Battery 12V - 16Amp Hour

Batteries & PV Panels

  • Battery Type 48V AGM Deep Cycle Solar Storage
  • Battery Capacity  1200AH (8x 150ah or 6x 200ah)
  • Panels Type Monocrystalline Silicon Tempered Glass
  • Panels Quantity 4x 300W
  • Charging MPPT Charging

Fuel & Running Hours (Optional Where Generator is Required)

  • Material Metal Self Bunded Tank
  • Capacity 13.5L
  • Metering & Level Display Yes - Mechanical
  • Total Running Hours 15 Hours Without Generator

Lighting Characteristics

  • Lighting 4 x 350W LED
  • Lumens 210 000
  • Type of Lamp Rectangle Type LED Lamp
  • Individual LED Switch On/Off Yes
  • Night Sensor Yes
  • Power Plug In Charger Yes
  • Lamp No. 4 Lamps / Mast
  • Total Lighting Area Sqm (m2) 5000

Mast Tower Characteristics

  • Type Telescopic
  • Total Height 8M
  • Section Type Multi-Sections
  • Wind Speed 80KM/H
  • Rotation 350 Degrees
  • Lights Tiltable Yes Manually
  • Operation Type Manual Operated

Weights & Dimensions

  • Length  2200 mm
  • Width 1500 mm
  • Height 2500 mm
  • Weight (Dry) 1375 kg / 1730 kg (incl Gen)
  • Weight (Wet) 1375 kg / 1780 kg (incl Gen)

Products that is Fitted

Yanmar

L70N-DEGLT

(Optional)

NSM

K100E

(Optional)

SmartGen

ALC404

Plusrite

4 x 350W
