Electric Power Generation: Yanmar
Pure Energy Solutions for Sub-Saharan Africa
TNV Generator Engine
A Sustainable Future
The TNV power pack is designed to meet diverse user needs and market requirements. The compact but powerful, reliable power pack provides durable performance, high quality and versatility, while keeping the fuel efficiency and environmental friendliness. It makes the installation and maintenance simple and user-friendly.
Product Range Overview
Refer to the table below
Characteristics
- Engine Type Vertical Cylinder
- Power 8.2kW - 67kW
- Cylinder Three & Four
- Speed 1500 & 1800rpm
- Cooling Water Cooled
- Starting System Electric
- Injection Type Direct
- Emissions Regulations Non-Regulated Territories
Generator Specification Range
Overview
Prime Rated kW & kVA
- Model kW \ kVA
- 3TNV76 8.2 \ 8.4
- 3TNV88 12.2 \ 12.6
- 4TNV88 16.4 \ 17.0
- 4TNV84T 18.0 \ 20.0
- 4TNV98 30.7 \ 33.2
- 4TNV98T 37.7 \ 41.2
- 4TNV106 44.9 \ 49.2
- 4TNV106T 51.4 \ 56.2
-
Values are Rated at 1500rpm 50hz 400v, 1000masl 1.0pF 40 Deg C
Yanmar Green Challenge 2050
Mounting Configurations ( Standard )
SAE 5 - 7.5
SAE 3 - 7.5
SAE 3 - 11.5
DOWNLOAD:
Brochures
Technical Data Sheet
Options
Drawings
Maintenance and Parts Manual
