Electric Power Generation: Nidec Power - ASI Generators
Pure Energy Solutions for Sub-Saharan Africa
ASI Generators
The Best of Performance
Nidec has a complete line of LV and HV generators up to 60 MVA. The range includes both synchronous and induction machines. Our sweet spots include: on-board power generation for marine applications, electric generator solutions for co-generation and biomass plus hydrogenerators for small and large hydropower stations.
Whatever your application, Nidec ASI will meet your needs and will adapt to all situations.
Marine Generators
- Power Rating: 2,500 – 16,000 kVA
- Voltage: up to 11 kV
- Pole Number: 4 – 14
- Frame Size: 560 mm – 11
Generators for ORC Turbines
- Power Rating: 4.600-45.000 kVA
- Voltage: 4.160-13.800 V
- Mass: 17.500-76.000 kg
- Number of Poles: 4-pole or directed couple 2-pole machines
Generators for Diesel and Gas Engines
- Power Rating: 150 – 45.000 kVA
- Voltage: up to 15 kV
- Mass: 1.500 – 160.000 kg
- Number of Poles: 2- 36
- Frame Size: 450 – 1120mm, 10, 11, 12, 13
- Type of Cooling: IC 01/06, IC 81W, IC 611, IC31
- Degree of Protection: IP23, IP24, IP44
- Mounting Arrangement: horizontal or vertical
Generators for Steam and Gas Turbines
- Power Rating: 150 – 45.000 kVA
- Voltage: up to 15 kV
- Mass: 1.500 – 160.000 kg
- Number of Poles: 2- 36
- Frame Size: 450 – 1120mm, 10, 11, 12, 13
- Type of Cooling: IC 01/06, IC 81W, IC 611, IC31
- Degree of Protection: IP23, IP24, IP44
- Mounting Arrangement: horizontal or vertical
Experience Across All Sectors
DOWNLOAD:
Brochures
Technical Data Sheet
Options
Drawings
Maintenance and Parts Manual
